Product Data Sheet Show all documents
Sikalastic®-800 HA

Sikalastic®-800 HA

2-PART POLYUREA HYBRID ELASTIC WATERPROOFING MEMBRANE

Sikalastic®-800 HA is a two component, solvent free, highly elastic, low odour polyurea hybrid waterproofing membrane.
Due to its self-levelling properties Sikalastic®-800 HA is ideal for applications on protected podium decks and will provide a jointless surface, fully bonded, with crack bridging abilities.

  • Cold applied, self levelling behaviour
  • Desired thickness in one layer application
  • Low odour product during and after the application
  • High flexibility
  • May be combined with Sika Extender T for vertical applications
  • Can be covered with an aliphatic top coat for exposed applications
  • Good adhesion to most substrates
Product Data Sheet Show all documents

Usage

  • Sikalastic®-800 HA can be hand applied by notched rubber or metal squeegees to obtain the desired thickness
  • Sikalastic®-800 HA is a flexible elastomeric product with crack bridging properties
  • Sikalastic®-800 HA is an economic waterproofing solution. Smaller areas up to 150 m2 can be coated without the need for application machinery


Advantages

  • Cold applied, self levelling behaviour
  • Desired thickness in one layer application
  • Low odour product during and after the application
  • High flexibility
  • May be combined with Sika Extender T for vertical applications
  • Can be covered with an aliphatic top coat for exposed applications
  • Good adhesion to most substrates

Packaging

20.2 Litres (25 Kg) mixed packs A+B:

Part A:

4.7 Litres ( 9.2 kg)

Part B:

15.5 Litres (15.8 kg)

Product Details

Sustainability / Certifications / Approvals

APPROVALS / STANDARDS

  • Conforms to the requirements of EN 1504-2:2004
  • Reaction to fire according to EN 13501-1: Euroclass E
  • Root resistance tested according to DIN CEN/TS 14416 report number 0078.0.2-2019e performed at KIWA Institute in Germany
  • MOB PF2 PS/SPU T42.00 Pedestal Structure and Fixing Test
  • BBA Certificate No. 21/5942 Product Sheet 1 and 2
Product Information

Chemical Base

Elastomeric Polyurea hybrid

Shelf Life

12 months from date of production

Storage Conditions

Store properly in original, unopened and undamaged sealed packaging, in dry conditions at temperatures between +5°C and +30°C.

Density

~ 1.24 Kg/l (mixed A+B)

(DIN EN ISO 2811-11)

Solid content by mass

100% (Part A: 100%, Part B: 100%)

Solid content by volume

100% (Part A: 100%, Part B: 100%)


Volatile organic compound (VOC) content:   ~0.09 g/litre
Technical Information

Shore A Hardness

75

(BS ISO 7619)

Tensile Strength

10.0 N/mm2

(DIN EN ISO 527-3)

Crack Bridging Ability

Crack briding to EOTA TR013

Pass

Tensile adhesion strength

3.2 N/mm2

Value measured over Sikalastic® Primer 01

(DIN EN ISO 4624)

Tear Strength

13.8 N/mm2

(DIN EN ISO 6383)

Chemical Resistance

Resistant to mild acids, alkalis, detergents and some solvents. More details are available on request. Please contact your technical representative.

Application

Application Information

Mixing Ratio

Part A: Part B = 1 : 1 volume

Layer Thickness

2mm depth

Ambient Air Temperature

+2°C min. / +40°C max.

Relative Air Humidity

35% min / 80% max.

Dew Point

Beware of condensation!
The substrate and uncured floor must be at least 3°C above dew point to reduce the risk of condensation or blooming on the Sikalastic®-800 HA finish

Substrate Temperature

+2°C min. / +40°C max.

Substrate Moisture Content

<4% pbw moisture content.
Test method: Sika®-Tramex meter, CM - measurement or Oven-dry-method. No rising moisture according to ASTM (Polyethylene-sheet)

Pot Life

~25 minutes at +20°C
Note: Pot life will decrease at higher temperatures and increase at lower temperatures.


Estimated values of Sikalastic®-800 HA


Ambient Conditions

Rain Resistant

Foot traffic

Full Cure

+10°C/50% r.h

3 hours1

10 hours

28 hours

+20°C/50% r.h

2 hours1

6 hours

24 hours

+30°C/50% r.h

1 hour1

4 hours

20 hours

Maximum waiting time between coats of Sikalastic®-800 HA is 3 days

1  Impact from heavy rain or rain showers can still physically mark or damage the membrane


Consumption

Consumption

25 kg of Sikalastic®-800 HA will cover approximately 10 m2
Application steps

SUBSTRATE PREPARATION

Substrate Pre-Treatment


Surface defects should be repaired with appropriate scratch coat materials.  See method statement.


Substrate

Primer

Cementitious substrates

Sikalastic® Primer-01. Sika® Concrete Primer or Sikafloor®-151 lightly broadcast with quartz sand, 0.3–0.8 mm (Sikafloor®-151 only)

Metals and Ferrous or galvanised metals or stainless steelSikalastic® Metal Primer

For the consumption rates and waiting time / overcoating please refer to the PDS of the appropriate primer. Other substrates must be tested for their compatibility. If in doubt, apply a test area first.

Sika highly recommend double priming substrates before application of Sikalastic®-800 HA.

The surface must be sound, of sufficient strength, clean, dry and free of dirt, oil, grease and other contamination. Depending on the material the substrate must be primed or mechanically cleaned. Grinding may be necessary to level the surface. Suitable substrates are concrete, metal and brickwork.
For detailed information on Substrate Preparation refer to the Sikalastic®-800 HA Method Statement.

MIXING

Prior to mixing, stir Part A mechanically. When all of Part A has been added to Part B, mix continuously for 2 minutes until a uniform mix has been achieved. To ensure thorough mixing pour materials into another container and mix again to achieve a consistent mix. Over mixing must be avoided to minimise air entrainment.
Mixing Tools:
Sikalastic®-800 HA must be thoroughly mixed using a low speed electric stirrer (300 - 400 rpm) or other suitable equipment.

Documents
